PP Woven CI Flexo Press is a specialized central impression (CI) flexographic printing machine designed for PP (polypropylene) woven fabrics. This high-performance press is tailored for medium-to-long production runs, delivering high-quality, precise, and stable printing on PP woven materials, which are often challenging due to rough surfaces, poor ink adhesion, and material stretching.
Clear Printing on Rough Surfaces: Optimized for PP woven fabric texture, preventing fuzzy patterns.
Stable Ink Adhesion: Reduces peeling or smudging of ink.
Precise Registration: Minimizes color misalignment and ensures consistent multi-color printing.
High Efficiency: Supports medium-to-long production runs, boosting productivity and reducing downtime.
Material Handling Optimization: Prevents stretching or deformation during printing.
The PP Woven CI Flexo Press is widely used across industries requiring high-quality printing on PP woven fabrics. Its advanced central impression (CI) design ensures precision, stable ink adhesion, and consistent multi-color output.
1.PP Woven Bags
●Shopping bags, tote bags, and promotional packaging.
●Ensures sharp logos, patterns, and brand designs.
2.PP Woven Sacks
●Industrial packaging for food, fertilizer, chemicals, feed, and grains.
●Resistant to ink peeling and color misregistration.
3.Industrial Packaging Materials
●Liners, wraps, and sheets for logistics, storage, and transportation.
●Handles rough surfaces and large production runs efficiently.
4.Custom Branded Packaging
●Flexible multi-color printing for promotional or retail packaging.
●Supports small to medium-sized batch customization.
5.Other PP Woven Products
●Tarpaulins, reusable shopping bags, shopping sacks, and protective covers.
●Ideal for medium-to-long production runs with consistent quality.
| Model | HPCI-600B | HPCI-800B | HPCI-1000B | HPCI-1200B |
| Number of printing group | 4/6/8 | |||
| Max.web width | 650 | 850 | 1050 | 1250 |
| Max.printing width | 600 | 800 | 1000 | 1200 |
| Max.machine speed | 250m/min | |||
| Max.printing speed | 200m/min | |||
| Max.unwind/rewind Dia. | 800mm | |||
| Drive type | Central drum with gear drive | |||
| Ink | Water base ink or solvent ink | |||
| Printing lengh(repeat) | 350-800MM | |||
| Range of sbstrates | PP Wowen Bags,Paper-plastic bags | |||
| Electrical supply | Voltage 380v,50hz or to be specified | |||
● The machine introduction & absorption of European technology / process manufacturing, supporting / full functional.
● After mounting the plate and registration, no longer need registration, improve yield.
● Replacing 1 set of Plate Roller (unloaded old roller, installed six new roller after tightening), only 20 Minute registration can be done by printing.
● The machine first mount plate, pre-trapping function, to be completed in advance prepress trapping in the shortest possible time.
● Maximum production machine speed up 200m/min, registration accuracy ±0.10mm.
● The overlay accuracy does not change during lifting running speed up or down.
● When machine stop, Tension can be maintained, the substrate is not deviation shift.
● The whole production line from the reel to put the finished product to achieve non-stop continuous production, maximize product yield.
● With precision structural, easy operation, easy maintenance, high degree of automation and so on, only one person can operate.
1,Center-driven unwinding, equipped with magnetic powder brake, equipped with automatic tension control；
2,Tension control: Ultra-light floating roller control, automatic tension compensation,closed loop control;
3,It has the function of automatic shutdown when the material is interrupted, and the tension maintains the function to avoid the substrate slack and deviation during the shutdown
4, Configure automatic EPC system before printing EPC: Before printing, a four-roller automatic EPC ultrasonic probe correction system has manual/automatic/center return functions, and the left and right translation can be adjusted by ±65mm.
1，Type : CI Flex Printing Machine
2，Color: 4 colors on the front + 4 colors on the back
3，Drive mode: Servo gear drive
4，Motor: Servo motor drive, inverter control closed loop control
5，Printing method :Photosensitive resin plate, suitable for both water-based and alcohol-soluble inks
6，Printing Repeat: 400-1200mm
1,Check range: depends on the material width, arbitrarily setting. It is ok for adjustable point monitor or automatic back and forth.
1,Double-station Surface friction winding, Equipped with servo cutter, stable segment length
2,The tension control adopts ultra-light floating roller control, automatic tension compensation, closed-loop control, and arbitrary setting of taper tension (low-friction cylinder position detection, precision pressure regulator control, automatic alarm or shutdown when the roll diameter reaches the set value)
1.What is a PP Woven CI Flexo Press used for?
It is used for high-quality, multi-color printing on PP woven fabrics, including bags, sacks, and industrial packaging materials.
2.What problems does this machine solve?
It addresses fuzzy printing, ink peeling, color misregistration, and fabric stretching issues common in PP woven material printing.
3.What types of PP woven materials can it print on?
Suitable for PP woven bags, sacks, sheets, and other flat or tubular woven fabrics.
4.What are the production advantages?
Ensures stable, high-speed, and precise printing for medium-to-long production runs, reducing waste and downtime.
5.Can it handle multi-color printing?
Yes, the CI design supports accurate multi-color registration and consistent output quality.
6.Who should consider purchasing this machine?
Manufacturers of PP woven bags, industrial packaging, or promotional products looking for efficient, high-quality printing.
7.What brands or manufacturers provide this machine?
Reliable suppliers include HuiPeng, a professional manufacturer of CI flexo presses with strong R&D and quality assurance.
8.Is customization possible?
Yes, print width, color stations, and other specifications can be customized based on production needs.
