CI Sleeve Type refers to a flexographic printing press that adopts a Central Impression (CI) structure and uses sleeve-type flexible printing plates. This printing press achieves an efficient and precise printing process by making flexible printing plates into sleeves (plate sleeves) and installing them in the printing unit. The sleeve design simplifies the plate changing process, significantly improving production efficiency and print quality, and is widely used in multi-color flexographic printing of plastic films, paper, and composite materials.
1.The frame is made of alloy cast iron with high strength and lower stress. It is casted by resin sand process and treated by vibration aging.
2.Integral type guide roller structure.
3.Assembled modularization in design.
4.Frame thickness 100mm
5.Guide roller Φ100mm (Surface anodic oxidation treatment)
Central Impression Structure
The paper or film material closely adheres to the central impression cylinder, ensuring good tension control and high-precision registration.
Sleeve-type Plate System
Flexible plates are made into sleeves, making them easy to replace and maintain, reducing setup time and increasing production efficiency.
Multi-color Printing Capability
Supports multi-station, multi-color printing to meet the packaging industry's demand for complex patterns and color printing.
High Speed and Efficiency
The machine is designed for high-speed operation, meeting the requirements of large-scale continuous production.
Automated Control
Digital operation control, automatic tension and registration adjustment, simplifying operation and ensuring continuous and stable printing.
Drying and Curing System
Equipped with hot air, infrared, or UV drying equipment to quickly cure ink and ensure print quality.
Environmentally Friendly Design
Supports water-based and UV eco-friendly inks, complying with green printing standards.
Plastic films (such as BOPP, PET, CPP, etc.)
Paper and composite packaging materials
Other flexible packaging materials
| Model | HPCI-600B | HPCI-800B | HPCI-1000B | HPCI-1200B |
| Number of printing group | 4/6/8 | |||
| Max.web width | 650 | 850 | 1050 | 1250 |
| Max.printing width | 600 | 800 | 1000 | 1200 |
| Max.machine speed | 250m/min | |||
| Max.printing speed | 200m/min | |||
| Max.unwind/rewind Dia. | 800mm | |||
| Drive type | Central drum with gear drive | |||
| Ink | Water base ink or solvent ink | |||
| Printing lengh(repeat) | 350-800MM | |||
| Range of sbstrates | PP Wowen Bags,Paper-plastic bags | |||
| Electrical supply | Voltage 380v,50hz or to be specified | |||
The CI Sleeve Type printing machine is widely used across diverse packaging and labeling industries, delivering high-quality and precise printing solutions. Its application areas include:
1.Food Packaging Film Printing
Ideal for flexible films in snacks, beverages, confectionery, and frozen food, ensuring vibrant colors and durable prints.
2.Labels and Tags Printing
Perfect for product labels, price tags, and promotional stickers, providing accurate registration and high-resolution graphics.
3.Paper Packaging and Corrugated Carton Printing
Suitable for paper bags, cartons, and folding boxes, offering consistent print quality for branding and decorative purposes.
4.Pharmaceutical and Daily Consumer Goods Packaging
Used in medicine boxes, cosmetic packaging, and household goods, ensuring compliance with safety standards and premium print finish.
5.Industrial and Specialty Packaging
Applicable for chemical, electronic, and specialty packaging where precise registration and sharp graphics are required.
This CI Sleeve Type printer from HuiPeng meets the needs of global manufacturers seeking high-efficiency, reliable, and factory direct printing solutions made in China.
Quick sleeve plate replacement greatly shortens downtime and increases production efficiency
Central impression design ensures precise multi-color registration and stable print quality
Multi-color printing meets high-quality packaging printing requirements
Highly automated, easy to operate, reducing human error
Environmentally friendly and energy-saving, supporting green printing materials and processes
The CI Sleeve Type Flexographic Printing Machine combines central impression technology with a sleeve plate system, suitable for modern multi-color, diverse, and efficient packaging printing, making it an ideal choice for improving production efficiency and print quality.
The Sleeve Type CI Flexo Printing Machine developed by Jinjiang HuiPeng Printing Machinery Co., Ltd. is designed for high-precision flexible packaging printing. As a professional CI flexo printing machine manufacturer in China, HuiPeng integrates advanced sleeve technology with a central impression (CI) structure to deliver stable color registration, faster job changeovers, and higher production efficiency.
This sleeve type CI flexo press is widely used for printing materials such as plastic film, paper, nonwoven fabrics, aluminum foil, and laminated materials. With excellent printing consistency and reduced setup time, it is an ideal solution for modern packaging converters seeking productivity and quality.
The sleeve system allows operators to quickly replace printing sleeves without removing the entire printing cylinder. This significantly reduces downtime and improves production efficiency, especially for short-run or multi-order printing jobs.
The CI drum structure ensures stable substrate tension and excellent color registration. Even at high printing speeds, the machine maintains consistent print quality across long production runs.
Advanced servo control systems and precision mechanical components provide smooth operation, minimizing vibration and ensuring stable ink transfer throughout the printing process.
Sleeve technology simplifies plate mounting and reduces material waste during setup. Operators can achieve accurate registration faster, improving overall production efficiency.
With years of experience in flexographic printing equipment manufacturing, HuiPeng combines advanced engineering with strict quality control standards. Our machines are developed by an experienced technical team with deep industry expertise, ensuring stable performance and long-term reliability.
1. What is a sleeve type CI flexo printing machine?
A sleeve type CI flexo printing machine uses lightweight printing sleeves instead of traditional cylinders. The sleeves can be quickly mounted or replaced, improving efficiency and reducing downtime during printing plate changes.
2. What materials can this flexo printing machine print?
The machine can print a wide range of materials including plastic films (PE, PET, BOPP), paper, aluminum foil, nonwoven fabrics, and laminated flexible packaging materials.
3. What are the advantages of sleeve technology?
Sleeve technology allows faster job changeovers, easier plate mounting, improved registration accuracy, and reduced material waste during setup.
4. Can the machine be customized according to production requirements?
Yes. HuiPeng can customize the machine configuration according to customer requirements, including printing width, number of colors, drying system, and automation features.
5. Do you provide installation and operator training?
Yes. Our engineers can travel to the customer's factory to install the machine, conduct debugging, and provide comprehensive operator training to ensure smooth production.
6. How do you ensure machine quality?
Each HuiPeng printing press undergoes strict quality inspection and performance testing before shipment to guarantee reliability and printing accuracy.
7. What after-sales services do you provide?
We offer long-term technical support, remote troubleshooting, and on-site service when necessary. Our after-sales team responds within 24 hours to assist customers with any equipment issues.
8. How long is the delivery time?
Delivery time depends on machine configuration and customization requirements. Generally, production takes around 60–90 days after order confirmation.
